Rig-23
2,000 HP
Power System:
Diesel – Electric Land Rig
4 x MTU Detroit 1480 HP engines
4 x 1720 kVA KATO Generators
M&I Power Control Room (SCR)
Diesel Capacity: 70,000 + 65,000 Ltr
Circulation System:
System Pressure Rating: 5,000 psi
Mud Tank Capacity: 3,300 bbl
Each tank equipped with Agitators
3 x Gardner Denver PZL-11 Mud Pumps
Each Mud Pump 2 x GE 752 DC Motor
Liner size: 5-1/2” – 7”
Solids control Equipment:
3 x MI Mongoose Max, Derrick Mud Cleaner, 3 x
12” Desander cones, 16 x 4” Desilter cones,
SWACO Vacuum degasser
Hoisting System:
Drawworks Gardner Denver 2100 E, 2000 HP
2 x GE 752, DC Motors
Mechanical & ELMAGCO Brake
Drilling line: 1-1/2” IWRC, 6 x 19
6 + 1 Sheaves 60” Crown Block
550 T Gardner Denver Travelling Block
Mast: 156 ft. Pyramid 1,000,000 lbs
Sub-structure: 25 ft.
Well Control :
Blow Out Preventer: 21-1/4”- 2K & 13-5/8” – 10K
Stack (Cameron)
Annular, Upper pipe ram, Blind/Shear Ram,
Lower Pipe Ram*
Accumulator Unit: Koomey, 32 Bottles, 3,000 Psi
Safety Valves
Cameron Choke Manifold 10,000 psi
Mud Gas Separator: 48” body Outer Diameter
Rotating System:
Top Drive System: Varco 11S
800 HP, AC Driven, 500 T capacity, Integrated ,Swivel
Rotary Table: National C-375
Rig-23
Power System:
Diesel – Electric Land Rig
4 x MTU Detroit 1480 HP engines
4 x 1720 kVA KATO Generators
M&I Power Control Room (SCR)
Diesel Capacity: 70,000 + 65,000 Ltr
Circulation System:
System Pressure Rating: 5,000 psi
Mud Tank Capacity: 3,300 bbl
Each tank equipped with Agitators
3 x Gardner Denver PZL-11 Mud Pumps
Each Mud Pump 2 x GE 752 DC Motor
Liner size: 5-1/2” – 7”
Solids control Equipment:
3 x MI Mongoose Max, Derrick Mud Cleaner, 3 x
12” Desander cones, 16 x 4” Desilter cones,
SWACO Vacuum degasser
Hoisting System:
Drawworks Gardner Denver 2100 E, 2000 HP
2 x GE 752, DC Motors
Mechanical & ELMAGCO Brake
Drilling line: 1-1/2” IWRC, 6 x 19
6 + 1 Sheaves 60” Crown Block
550 T Gardner Denver Travelling Block
Mast: 156 ft. Pyramid 1,000,000 lbs
Sub-structure: 25 ft.
Well Control
Blow Out Preventer: 21-1/4”- 2K & 13-5/8” – 10K
Stack (Cameron)
Annular, Upper pipe ram, Blind/Shear Ram,
Lower Pipe Ram*
Accumulator Unit: Koomey, 32 Bottles, 3,000 Psi
Safety Valves
Cameron Choke Manifold 10,000 psi
Mud Gas Separator: 48” body Outer Diameter
Rotating System:
Top Drive System: Varco 11S
800 HP, AC Driven, 500 T capacity, Integrated ,Swivel
Rotary Table: National C-375
